KUKKO 20-00 2-arm universal puller, clamping range up to 95 mm, 75 mm clamping depth

Based on the ingenuity and pioneering spirit of Alfred Kleinbongartz, the universal pullers with sliding, always parallel jaws of the series 20 receive a functional upgrade. Operating comfort and user-friendliness are at the forefront. Concretely, the following optimizations have been implemented: For even more flexibility when pulling, the puller program has been extended with two sizes (20-0 and 20-00). This creates a clamping range of 0 to 750 mm for external pulling and a maximum pulling force of 2.5 to 15 t. To increase load capacity, the pullers are equipped with reinforced shoulders, resulting in a stable H-profile. This is thanks to the newly thought-out, innovative construction of the cross-arms, which guarantees maximum stability even under high pulling force. Above the cross-arms, a scale serves as an orientation aid for evenly shifting the jaws, allowing safe adjustment of the jaws. Below the cross-arms, next to the replacement article number of the cross-arms for reordering, there is another six-digit number. The first three digits indicate which spindle is compatible with the cross-arms. The last three digits (xxx) mark the variable spindle length, which varies from 85 mm to 600 mm depending on the version. In addition to mechanical spindles with a different thread length, and depending on the size of the puller, grease-hydraulic spindles can also be used as part of a hydraulics upgrade for easy and controlled pulling of particularly stubborn parts. Another advantage is the two eyes on the side of the cross-arms for attaching a tool tether (series 660), which additionally secures the puller and ensures safe fixation during work or storage. The 2-arm universal pullers with adjustable and robust standard jaws are used for particularly safe pulling of bearings, gears, and discs in all common sizes for trade, workshop, and industry. This way, any part that sits on a shaft and is freely accessible from the outside can be removed. By simply turning the jaws around, the pullers can also be used as internal pullers. Screw connection allows easy loosening and very firm tightening of the jaws with a hex key. Application also for eccentric parts thanks to freely moving jaws sliding on the cross-arm.

Specifications

• Dimensions: 120 × 133 × 29 mm
• Weight: 1 kg
• Material: Tool steel
• Series: 20-Classic
• Manufacturer: KUKKO
• Country of origin: Germany
• EAN: 4021176042317
