KUKKO 22-2 Counterstay, Range up to 100 mm

The controlled counterpart to the slide hammer. The counterstay braces on the housing around the bore with two legs, after which the spindle draws the bearing out evenly. You feel exactly how much force is on it and can stop the moment something is not right — on an aluminium housing that is the difference between a removed bearing and a cracked seat.

The legs are height-adjustable so the stay stands firm on an uneven housing too. Combine it with the internal pullers from the 21 series; the coupling is the same across the whole range.

Specifications

• Clamping range: tot 100 mm
• Clamping depth: 165 mm
• Design: in hoogte verstelbare poten
• Dimensions (w × h × d): 190 × – × 52 mm
• Material: tool steel
• Weight: 1.873 kg
• Series: 22
• Parts group: IN22
• Manufacturer: KUKKO, Remscheid (Germany)
