KUKKO 18-1 Pulling Device, 60-150/200 mm

The pulling device that gives the separating knife its force. Three spindles engage the separator and draw the assembly evenly off the shaft — with the bridge as counterstay, so the load stays neatly in line with the shaft.

The clamping depth determines how far from the shaft centre you can still pull; this model reaches 200 mm, covering most drive shafts and gearboxes. The connection is M10, matching the rest of the range.

Specifications

• Clamping range: 60 – 150 / 200 mm
• Clamping depth: 200 mm
• Connection: M10
• Dimensions (w × h × d): 182 × – × 35 mm
• Material: tool steel
• Weight: 2 kg
• Series: 18
• Parts group: TR18
• Manufacturer: KUKKO, Remscheid (Germany)
